Belts for Electronic Component Manufacturing
In the electronics manufacturing field, flat belts play key role in offering precise movement for power transmission and conveyor systems that are required in electronic component assembly lines to complement the automatic operation.
Below you will find our range of power transmission belts, machine tapes and conveyor belts for electronics manufacturing. Contact our experts, they'll be happy to assist you.
- Machine Belting
- Elastic Conveyor Flat Belt
- Polyester Power Transmission Belt
- TPU Transmission Belt
- Extraline Flat Belt
Machine Belting
DU3/15EL-A
- Material: 2 plies of thermoplastic polyurethane (TPU)
- Construction: TPU / TPU
- Thickness: 1.5 mm (±0.1mm)
- Color: green / black
DU40/11EL-A
- Material: 2 plies of thermoplastic polyurethane (TPU)
- Construction: TPU/TPU
- Surface structure: rough structure
- Thickness: 1.1mm (±0.1mm)
DUU12FLL
- Material: 2 plies of thermoplastic polyurethane (TPU)
- Construction: TPU/TPU
- Surface structure: rough structure
- hickness: 1.2mm (±0.1mm)
DUU15FLL
- Material: 2 plies of thermoplastic polyurethane (TPU)
- Construction: TPU / TPU
- Surface structure: rough structure
- Thickness: 1.5mm (±0.1mm)
DU20/11EL-HC
- Material: 2 plies of polyurethane (PUR), 1 ply of thermoplastic polyurethane (TPU)
- Construction: PUR/TPU/PUR
- Thickness: 1.1mm (±0.1mm)
- Color: black /black
UEU8N/G
- Material: 2 plies of thermoplastic polyurethane (TPU), 1 ply of polyethylene terephthalate (PET)
- Construction: TPU / PET / TPU
- Thickness: 1.5mm (±0.1mm)
- Color: dark green / dark green
UU6E/14GB+AN
- Material: 2 plies of thermoplastic polyurethane (TPU), 1 ply of polyethylene terephthalate (PET)
- Construction: TPU / PET / TPU
- Surface finish: double-sided matte finish
- Thickness: 1.4mm (±0.1mm)
UE-06AN
- Material (top /bottom): soak PUR+PET / TPU
- Surface finish (top /bottom): fabric texture / fabric texture
- Material of tension member: polyester fabric
- Color (top /bottom): black / black
DUU10VL/A
- Material: 2 plies of thermoplastic polyurethane (TPU)
- Construction: TPU / TPU
- Surface structure (top /bottom): velvet / rough
- Thickness: 1.0mm (±0.1mm)
DUU09R/C
- Material: 1 ply of thermoplastic polyurethane (TPU), 1 ply of polyurethane (PUR)
- Construction: TPU / PUR
- Surface finish: matte finish
- Thickness: 1.3mm (±0.1mm)
CNASWR SGT04
- Material: 1 ply of rubber, 1 ply of polyamide (PA) and 1 ply of sized fabric
- Construction: rubber / PA / sized fabric
- Thickness: 1.2mm (±0.1mm)
- Color: green / black
SGT06
- Material: 1 ply of nitrile butadiene rubber (NBR), 1 ply of polyamide (PA) and 1 ply of starched cloth
- Construction: NBR / PA / starched cloth
- Thickness: 1.5mm (±0.1mm)
- Color: vivid green / black
NALAR FN80/20BB
- Material: 2 plies of nitrile butadiene rubber (NBR), 1 ply of polyamide (PA)
- Construction: NBR / PA / NBR
- Thickness: 2.0mm (±0.1mm)
- Color: blue / black
NALAR DFN10
- Material: 2 plies of fiber, 1 ply of polyamide (PA)
- Construction: fiber / PA / fiber
- Thickness: 1.0mm (±0.1mm)
- Color: blackish green / black
NALAR F40/10GB
- Material: 2 plies of nitrile butadiene rubber (NBR), 1 ply of polyamide (PA)
- Construction: NBR / PA / NBR
- Thickness: 1.0mm (±0.1mm)
- Color: grass green /black
DK-06AN
- Material: 2 plies of soaking fabric, 1 ply of polyamide (PA)
- Construction: soaking fabric / PA / soaking fabric
- Thickness: 1.2mm (±0.1mm)
- Color: black / black
NBB-GG10AN
- Material: 1 ply of nitrile rubber, 1 ply of nitrile butadiene rubber (NBR)
- Construction: nitrile rubber / PA / NBR
- Thickness: 1.0mm (±0.1mm)
- Color: black /black
CNASWR DK-07AN
- Material: 2 plies of soaking fabric, 1 ply of polyamide (PA)
- Construction: soaking fabric / PA / soaking fabric
- Thickness: 1.5mm (±0.1mm)
- Color: black /black
CNASWR NBB-GG10AN
- Material: 1 ply of nitrile rubber, 1 ply of nitrile butadiene rubber (NBR)
- Construction: nitrile rubber / PA / NBR
- Thickness: 1.0mm (±0.1mm)
- Color: black /black
CNASWR NBB - GG20AN
- Material: 1 ply of nitrile rubber, 1 ply of nitrile butadiene rubber (NBR)
- Thickness: 2.0mm (±0.1mm)
- Color: black /black
- Min. pulley diameter: 50mm
UEU8N/G
- Belt thickness: approx.1.5mm (±0.1mm)
- Material (top /bottom): TPU / TPU
- Surface structure (top /bottom): fine structure / fine structure
- Material of tension member: PET
Elastic Conveyor Flat Belt
DU40/11EL-A
- Material: 2 plies of thermoplastic polyurethane (TPU)
- Construction: TPU/TPU
- Surface structure: rough structure
- Thickness: 1.1mm (±0.1mm)
DUU12FLL
- Material: 2 plies of thermoplastic polyurethane (TPU)
- Construction: TPU/TPU
- Surface structure: rough structure
- Thickness: 1.2mm (±0.1mm)
DUU15FLL
- Material: 2 plies thermoplastic polyurethane (TPU)
- Construction: TPU / TPU
- Surface structure: rough structure
- Thickness: 1.5 mm (±0.1mm)
DUU10VL/A
- Material: 2 plies of thermoplastic polyurethane (TPU)
- Construction: TPU / TPU
- Surface structure (top /bottom): velvet / rough
- Thickness: 1.0mm (±0.1mm)
DUU09R/C
- Material: 1 ply of thermoplastic polyurethane (TPU), 1 ply of polyurethane (PUR)
- Construction: TPU / PUR
- Surface finish: matte finish
- Thickness: 1.3mm (±0.1mm)
DU20/11EL-HC
- Material: 2 plies of polyurethane (PUR), 1 ply of thermoplastic polyurethane (TPU)
- Construction: PUR/TPU/PUR
- Thickness: 1.1mm (±0.1mm)
- Color: black /black
Polyester Power Transmission Belt
UEU8N/G
- Material: 2 plies of thermoplastic polyurethane (TPU), 1 ply of polyethylene terephthalate (PET)
- Construction: TPU / PET / TPU
- Thickness: 1.5mm (±0.1mm)
- Color: dark green / dark green
TPU Transmission Belt
UU6E/14GB+AN
- Material: 2 plies of thermoplastic polyurethane (TPU), 1 ply of polyethylene terephthalate (PET)
- Construction: TPU / PET / TPU
- Surface finish: double-sided matte finish
- Thickness: 1.4mm (±0.1mm)
UE-06AN
- Material (top /bottom): soak PUR+PET / TPU
- Surface finish (top /bottom): fabric texture / fabric texture
- Material of tension member: polyester fabric
- Color (top /bottom): black / black
Extraline Flat Belt
NBB-GG10AN
- Material: 1 ply of nitrile rubber, 1 ply of nitrile butadiene rubber (NBR)
- Construction: nitrile rubber / PA / NBR
- Thickness: 1.0mm (±0.1mm)
- Color: black /black
CNASWR DK-07AN
- Material: 2 plies of soaking fabric, 1 ply of polyamide (PA)
- Construction: soaking fabric / PA / soaking fabric
- Thickness: 1.5mm (±0.1mm)
- Color: black /black
CNASWR NBB-GG10AN
- Material: 1 ply of nitrile rubber, 1 ply of nitrile butadiene rubber (NBR)
- Construction: nitrile rubber / PA / NBR
- Thickness: 1.0mm (±0.1mm)
- Color: black /black
Dongji owns professional large-scale manufacturing plant and warehouse for polyurethane flat belts and polyamide power transmission belts. Ingenious manufacturing to the highest international standards has been central to Dongji's strategy since its inception. We are the first domestic industrial belt manufacturer using thermoplastic polyurethane (TPU) and nanomaterials to produce high-performance conveyor belts. The features of produced flat belts include energy saving, burr-free edge, antistatic property, high conductivity and good resilience, as well as outstanding resistance to abrasion, bending, chemicals, oil, and high or low temperatures, enabling the industrial belts versatile enough to accommodate the individual production process of diverse automatic manufacturing equipment.
